Drilling rigs are designed for drilling geophysical and structural/exploratory oil-and-gas wells, for exploring the deposits of solid minerals, construction materials, and groundwaters, for engineering and geological surveys, as well as for drilling water-intake and blast holes.
Drilling is done by rotation with subsequent washing or blowing of wells, or by means of augers.
Hydraulically-driven rotator moves along the mast and is used for drilling, for build-up of the drilling tool, as well as (when combined with a hydraulic jack) for lowering and lifting the tool and for feeding the tool when drilling. The rotator is moved along the mast by a hydraulic cylinder and a hoist system.
Rig controls are fully hydraulic; the rig is controlled from the operator's control unit.
|
DRILL SPECIFICATIONS: BASIC CONFIGURATION |
|
|
Drilling depth: - structural and exploratory wells for subsequent washing, m - geophysical wells for subsequent washing, m - geophysical wells for subsequent blowing, m - auger drilling, m Initial bore diameter with washing, mm |
300 to 350 100 30 to 50 30 190 |
|
Final bore diameter with washing: - for structural and exploratory wells, mm - for geophysical wells, mm |
93 118 |
|
Bore diameter with blowing, mm |
118 |
|
Auger bore diameter, mm |
135 to 200 |
|
Drill-string rotation speed, s-1 |
0.45 to 5.42 |
|
Maximum torque, Nm |
2,000 to 2,010 |
|
Rotator stroke, mm |
5,150 to 5,200 |
|
Drill-string lifting speed, m/s |
0 to 1.25 |
|
Rig weight, kg |
Up to 15,205 |
|
Pump model |
NB-50, NB-4 |
|
Maximum volumetric feed of the mud pump, m3/s |
0,011 |
|
Maximum pressure, MPa |
6,3 |
|
Compressor station |
KV-8/10; 10/10; 12/10 |
|
Compressor capacity, m3/min |
ADDITIONAL OPTIONS |
|
ADDITIONAL OPTIONS |
|
|
|
*Technical specifications are presented on this page for reference only, as the parameters and other operational indicators depend on the vehicle configuration of choice.
