Crew bus





Crew buses are designed for timely transport of crews (repair / construction / exploration crews, etc.) in a van-body cab to a site; transport can be done both along and off public roads.
     Crew-bus van bodies are made in two versions:
     1) Frameless design using sandwich panels and an angular profile; shaped as a rectangular prism. Sandwich panels are vacuum-formed, are self-supporting, and have a low thermal conductivity. Inner and outer facing of plated steel sheets. Styrofoam is used for thermal insulation. When assembled, the seams of the van body are sealed by a polyurethane-based sealant.
     2) Heat-insulated metal van-body with a welded frame.



CREW BUS SPECIFICATIONS: BASIC CONFIGURATION

Number of seats

8 to 34

Drop-side platform, type

Open drop-side platform / drop-side platform with an awning / closed drop-side platform

Van body

With / without side slopes

With / without cargo compartment

With a drop-side platform / with a drop-side platform and an inter-compartment door / without a drop-side platform

Production technology

1)Isothermal van body with S=60 mm thick panels Frameless, made of sandwich panels
Styropen insulation is a polystyrene material that has a density of 50 kg/m3 and a thermal conductivity of 0.0343 W/m*K.
2) Metal body, welded frame with thermal insulation

Outer and inner facing

Galvanized sheets with polymer coating (plated steel) / reinforced fiberglass

Packaging includes

1. Van body;

2. Lowered van aisle;

3. Lowered entrance

4. Glass-breaking emergency hammer (one outside and one inside the van)

5. Lights

6. Entrance backlight

7. Autonomous air heater

8. Air-heater duct tray;

9. Tosol heater powered by the vehicle cooling system;

10. Decorative cover for heater hoses;

11. Double seat with seat belts;

5. Emergency/ventilation hatch;

13. Double glazing for the door window;

14. Blind windows / leafed windows

15. Table

16. Front side door with a handrail (equipped with a reliable high-quality lock; triple-banded with a high-quality seal);

17. Rear side door (equipped with a reliable high-quality lock; triple-banded with a high-quality seal);

18. Door-opening limit switch;

19. Foldable ladder with a handrail;

20. First-aid kit bracket;

21. Handrail;

22. Door-opening limiter;

23. Fire extinguisher

24. Driver's cab intercom;

25. Accessories (chocks, an emergency-stop sign, a first-aid kit);

26. Window blinds;

27. Gearbox hatch;

28. Spare wheel

ADDITIONAL OPTIONS
  • Various configuration options
  • Folding-backrest seat
  • Under-seat stowage shelves
  • Armrests
  • Heater
  • Air conditioning
  • LCD TV with DVD, speakers, and a microphone
  • Car stereo
  • Any loader crane upon request


*Technical specifications are presented on this page for reference only, as the parameters and other operational indicators depend on the vehicle configuration of choice.
